Disease Digest

Introduction/Aetiology
Classification of the Causative Agent

Eubacteria, family Micrococcaceae, genus Renibacterium, species R. salmoninarum. Renibacterium salmoninarum is a Gram-positive nonsporulating, nonmotile coccobacillus that seems to act as an obligate parasite. It develops chronically in salmonid fish and results in late clinical disease.

Resistance to Physical and Chemical Action

Temperature: Optimum temperature for culture: 15oC. Preserved by refrigeration, freezing, freeze-drying.

Chemicals/
Disinfectants: Chlorine, quaternary ammonia, formalin, may be useful for disinfecting materials. However, transmission in ovo and the wide distribution of the pathogen in natural habitats limit the effectiveness of disinfection procedures.

Survival: Survival of this organism in the environment is poorly understood. It has been reported that the bacterium could remain viable in seawater for up to 1 week, and in the absence of other microflora, even longer. This duration of survival could be significant in a hatchery or netpen. May be hosted by nonsusceptible nonsalmonid species.

Epidemiology

Morbidity rate is high, due to vertical transmission.
Mortality is delayed but may become serious in highly infected populations.

Hosts

All salmonid species.

Transmission

Horizontal transmission may be direct, through contact with diseased fish and contaminated water, or indirect, through handling materials or feeding with fisheries residues.
Vertical transmission is the most frequent route of contamination. The bacteria are present in the ovarian fluids and are likely to be the source of the R. salmoninarum that have been detected in eggs from some infected female salmonids.

Sources of the Agent

Internal organs or skin tissues in cases of external lesions.
Eggs and coelomic fluid.
Inanimate vectors.
Many fish species, and even invertebrates, may be hosts of the pathogen without clinical manifestation.

Occurrence

Occurs in feral and farmed populations of salmonids in almost all areas where they are naturally distributed or have been acclimatised. No conclusive evidence has been reported for the presence of R. salmoninarum in the salmonid population of Australia, New Zealand, Russia, or some Mediterranean, countries.

For detailed information on occurrence, see recent issues of World Animal Health and the OIE Web site.

Diagnosis

Incubation period is long, and the clinical signs, often prompted by environmental causes, usually occur in fish over 1 year old.

Clinical Diagnosis

Dark coloration, exophthalmia and abdominal distension result from the destruction of interstitial kidney tissues.
Externally, haemorrhages may be observed at the base of the fins or at the vent, and the rupture of small cutaneous vesicles results in small ulcerations.
Greyish nodules or diffuse masses are generally observed in the kidney, spleen and liver. The kidney appears enlarged and the abdominal cavity is generally filled with fluid.

Lesions

Typical chronic infection characterised by granuloma scattered in the internal organs. A phagocytic reaction associated with more or less complete encapsulation may be observed. Caseous necrosis may be observed in advanced cases.

Differential Diagnosis

External manifestations are nonpathognomonic, but the course of the disease and the nature of the kidney lesions may provide presumptive indications. The disease must be differentiated from other kidney diseases of chronic progression including pseudo-kidney disease (Carnobacterium piscicola), nephrocalcinosis, and proliferative kidney disease. Confirmation must be by the observation and identification of the bacteria.

Laboratory Diagnosis
Procedures

Identification of the agent

Isolation and culture under appropriate conditions, completed by bacteriological identification or specific agglutination, require several weeks.
Antigen detection in infected tissues is more rapid.
Immunofluorescence (direct/indirect fluorescent antibody test [FAT and IFAT]).
Enzyme-linked immunosorbent assay (ELISA).
Polymerase chain reaction (PCR).

Serological tests

Not recommended. No positive correlation has been demonstrated between the antibody response and the course of the infection in fish populations.

Samples

Identification and isolation of the agent

Internal organs from diseased fish: kidney and spleen are the most convenient.
Tissue prints or smears for the detection of the antigen.
In maturing females, coelomic fluid is a reliable material and does not need to kill the fish.

Disease Prevention and Treatment
Sanitary Prophylaxis

Identification and culling of carrier broodfish.
Destruction or slaughtering of infected fish.
Disinfection of premises, materials and raceways.
Introduction of controlled pathogen-free stocks.

In infected areas, screening of asymptomatic carriers before spawning, and selection of breeders with the lowest levels of infection associated with erythromycin treatment have noticeably reduced the prevalence of the disease.

Treatment

Salmon
Trout

References

Chapter 2.2.6. in the OIE Diagnostic Manual for Aquatic Animal Diseases, OIE (World Organisation for Animal Health), Paris, France.
Chapter 2.2.6. in the OIE International Aquatic Animal Health Code, OIE (World Organisation for Animal Health), Paris, France

Cold Water Vibriosis

Introduction/Aetiology

Vibrio salmonicida, the agent of Hitra disease, a cold water vibriosis affecting Atlantic salmon (Salmo salar), is a facultatively anaerobic motile rod. This disease affects mainly fish farms with Atlantic salmon and occasionally with rainbow trout. Vibrio salmonicida has also been described as the aetiological agent of cold-water vibriosis affecting cod in Norway (Sorum et al., 1990). Hitra disease occurs mainly in late autumn, winter or early spring.

Epidemiology

Hitra disease appeared in 1977 and occurred for the first time on a large scale in 1979 in fish farms in the Norwegian island of Hitra. Since then, it has devastated fish farms located along the western and northern Norwegian coast (Egidius et al., 1981). However, single outbreaks have also been reported in Scotland (Bruno et al., 1985, 1986), on the Faroe Islands (Dalsgaard et al., 1988) and in New Brunswick and Nova Scotia, Canada (reference in Sorum et al., 1992).

Epidemiological studies based on plasmid profiles suggest that V. salmonicida was transmitted from cod to Atlantic salmon and vice versa in fish farms in northern Norway (Sorum et al., 1990).

Diagnosis

The characteristics of this disease, also known as haemorrhagic syndrome, are anaemia and haemorrhages with a generalized septicaemia, presenting large amounts of bacterial cells in the blood of moribund or recently dead fish. The haemorrhages are mainly found in the integument surrounding the internal organs of the fish ( Poppe et al., : Egidius et al.,)

Treatment

Salmon
Trout

References

© CAB INTERNATIONAL 1999. Fish Diseases and Disorders, Volume 3: Viral, Bacterial and Fungal Infections (eds P.T.K. Woo and D.W. Bruno)



Enteric Redmouth Disease [ERM]

Introduction

Enteric Redmouth Disease (ERM) is caused by the bacterial pathogen Yersinia ruckeri. The first instances of the disease were reported in Rainbow trout (Oncorhynchus mykiss) in the USA in the 1950s. Subsequent clinical outbreaks occurred in the UK in 1982 and in most other parts of Europe over the following few years. It is now endemic in all trout producing countries where it can cause severe economic losses. It is also becoming a more significant pathogen of farmed salmon, primarily in freshwater but it has been reported to cause losses in the sea as well.

According to estimates from within the British Trout Association in 1998, the cost of ERM in the UK trout industry alone was approximately 1.3-1.5 million per year. This figure is based on the costs of mortality, growth penalties and subsequent reduction in feed conversion rate, grading problems, withdrawal periods due to antibiotic treatments and subsequent harvesting delays as a result of the disease. This can be calculated as 10% of the production cost of the industry. Extrapolating these figures to the European trout industry producing 200,000 tons per year indicates ERM causes a potential economic loss of 20 million each year.

Aetiology

ERM is characteristically a disease of rising and falling water temperatures. The highest risk of disease occurs between 8o and 16oC although mortality can occur at temperatures as low as 4oC. At the higher temperatures mortality can rise quickly. Levels of 15 – 20 % have been reported even with antibiotic treatments. Fish of all sizes are affected, however, fish of 50 – 200g are the most susceptible. Stressful conditions such as high stocking densities and poor water quality will increase the level of susceptibility and mortality.
Species Common name

Salmonids
Oncorhynchus kisutch Coho salmon
Oncorhynchus mykiss Rainbow trout
Oncorhynchus nerka Sockeye salmon
Oncorhynchus tschawytscha Chinook salmon
Salmo clarkii Cutthroat
Salmo salar Atlantic salmon
Salmo trutta Brown trout
Salvelinus alpinus Arctic char
Salvelinus fontinalis Brook trout

Non-salmonids
Acipenser baeri Sturgeon
Anguilla anguilla Eel
Aristichthys nobilis Bighead carp
Carassius auratus Goldfish
Coregonus artedii Cisco
Coregonus peled Whitefish
Coregonus muksun Whitefish
Cyprinus carpio Common carp
Hypophthalmichthys molitrix Silver carp
Ictalurus punctatus Channel catfish
Lota lota Burbot
Notemigonus atherinoides Emerald shiner
Pimephales promelas Minnow
Scophthalmus maximus Turbot
Solea solea Sole

Symptoms

The most distinctive external and internal signs and symptoms of the disease are:

Black, lethargic fish “hanging” in areas of low flow at the edges of ponds and raceways or against outlet screens.
Bilateral exophthalmia
Abdominal distension as a result of fluid accumulation
Haemorrhages of the mouth and gills. The so-called “Redmouth” is rarely seen in acute infections but may be present in chronic infections.
General septicaemia with inflammation of the gut
Petechial haemorrhage of the pyloric caecae
Diffuse haemorrhages within the swim bladder. These are the most diagnostic symptoms of ERM
The spleen is often enlarged and can be almost black in colour

The external symptoms mentioned above are also seen with other bacterial and parasitic infections so some further diagnosis must be carried out. Yersinia ruckeri is easily isolated from diseased fish on TSA plates or preferably upon a semi-selective media designed for the purpose.

Following an incubation period of 24-48 hours shiny off-white colonies develop. Identity can be rapidly confirmed using specific antisera such as Mono YR test kits

Epidemiology

Known to be present over large areas of the USA and Europe (Denmark, France, Germany, Italy, Norway and UK). It is also present in Australia, South Africa and Chile, all of which received imported salmonid eggs and fry from these areas. However, there is some variation in the strains and serotypes within the genus associated with geographical areas and it cannot be ruled out that it is of a more widespread occurrence in a natural manner than was at first thought.

Treatment

Good husbandry can play an important part in limiting the level of mortality caused by ERM. Reducing stocking densities at times of high risk and avoiding stressful procedures such as grading will help.

Salmon
Trout

References

© CAB INTERNATIONAL 1999. Fish Diseases and Disorders, Volume 3:
Viral, Bacterial and Fungal Infections (eds P.T.K. Woo and D.W. Bruno)

Environmentally Compatable Aquaculture Industry

Aquaculture International, Inc., is a non-profit organization dedicated to the economically sound, environmentally compatible growth of the aquaculture industry through education and consultation. The organization is involved in the establishment on several practical and innovative demonstration facilities which are economically feasible and can be replicated by farmers, missionaries and other interested individuals.

The founder and president is Charles W. Johnson who has been involved in aquaculture education and extension since 1971.

The Board of Directors are:

Tom Slagle, Secretary, Dillsboro, NC – Family Counselor at Broyhill Children’s Home. He is especially gifted in the rehabilitation of disadvantaged persons.

Robert C. Carpenter, Franklin, NC – NC Senator for 16 years and founding president of the Southern Appalachian Trout Growers Association.

Clayton Davis, Maggie Valley, NC – Retired from the NC Cooperative Extension Service and NC Department of Agriculture. Developer and initial manager of the WNC Farmer’s Market.

Dr. Jerry West, Cullowhee,NC – Professor Emeritus of Biology, Western Carolina University. Founder and initial director of the WCU Mountain Aquaculture Center.

Aquaponics – A Promising Agricultural Alternative

What is aquaponics?

Aquaponics is the combining of aquaculture and hydroponics for mutual benefit. Through normal metabolic processes, the fish in the system excrete nutrient-rich waste into the water on which the plants flourish. As the plants utilize the nutrients, they purify the water for recirculation back to the fish.

Interest in aquaponics is increasing globally in response to more emphasis in resource management, sustainability, waste management and wholesome food supply production. It offers an attractive alternative to farmers who want to diversify. Existing resources can be utilized, such as abandoned farm buildings or greenhouses to house the fish and plants. Old fuel tanks or grain bins can be converted into fish production tanks. Water sources can include wells, springs, lakes and abandoned rock or sand quarries. Even captured rainwater can be a water source. A small scale pilot project can be set up inexpensively as a learning tool before expanding into a commercial operation.

The beauty of aquaponic systems is that they work with the natural balance. This allows the opportunity to produce and sell to the fastest growing segment of the food market in the US – organic. Organic products sell for a premium price because consumers are increasingly demanding foods which have not been exposed to toxic chemicals or pesticides. According to trends, demand for organically produced food products is expected to be greater than the overall supply.

Barrel Aquaponics Workshop

If you want to get started producing a constant supply of fish, vegetables and other plants in an efficient, inexpensive small-scale system, plan to attend this practical two day workshop. Each attendee will learn to construct and manage a variety of highly productive aquaponics systems from barrels and buckets. Dates and information will be posted when scheduled.

BARREL AQUAPONICS WORKSHOP

Aquaculture International will be conducting this practical workshop to be held at Camp Living Water near Bryson City, N.C., March 10 & 11, 2008. Instruction will focus on small-scale aquaponics, which is the combining of aquaculture and hydroponics for mutual benefit. Included in presentations will be barrel system construction, selecting fish and plants to produce, management practices, maintaining water quality, system balance, day-by-day operation, producing your own feed and considerations for expansion in various environments.

Each attendee will learn to construct a variety of highly productive, small-scale system from barrels and buckets, capable of producing fish and a large variety of vegetables, greens & herbs. This will serve as an innovative educational facility for students, an effective “helps ministry” outreach or a pilot learning facility before expanding to a larger operation.

This pre-conference workshop will lay a good foundation for getting the maximum benefit from attending the Aquaponics Conference. Note the discount for attending both.

WHO SHOULD ATTEND?

Vocational Agriculture or Science Teachers, Farmers, Interested Individuals, Missionaries and Others who are interested in using as an outreach ministry.

LODGING

The meeting facility and host lodging is at Camp Living Water, 1510 West Deep Creek Road, Bryson City, N.C. It adjoins the beautiful Great Smoky Mountains National Park. All rooms are $30/night single, $44/night double, including a big breakfast and payable upon arrival. Shared kitchen facilities are available at no extra charge. To reserve a room, call: 828-488-6012 or email dclw@dnet.net . For more information, go to: www.camplivingwater.com

Aquaponics Conference

This three day conference will focus on the construction and management of various successful, innovative and low-cost, integrated aquaponics operations. Aquaponics is the combining of aquaculture & hydroponics for mutual benefit. Dates and information will be posted when scheduled.

AQUAPONICS CONFERENCE

Are you interested in learning from experienced individuals how to produce a constant supply of fish and vegetables in a naturally balanced system as an innovative business, a school project, as an outreach in a needy neighborhood or even as a “Helps Ministry” in other countries? If so, you will want to attend the Aquaponics Conference held at Camp Living Water, Bryson City, NC, March 12 – 14, 2008. Presentations will include the in-depth examination of several highly successful and innovative aquaponics facilities. Course participants will learn the techniques of inexpensively constructing and managing these productive systems as well as integrating them to produce feed and energy from the waste. Field trips will be taken to a small-scale aquaponics facility, vertical strawberry production, a large commercial hydroponic lettuce greenhouse complex and a nearby trout farm.
Sessions will be informal, allowing plenty of time for questions and discussions. The enthusiasm among course participants and instructors will be high. If you are already involved in aquaponics, hydroponics, aquaculture or some related activities, bring a few photos on a CD to share with the class. It will be a great time of fellowship & learning – an event that you will always remember!

WHO SHOULD ATTEND?

Vocational Agriculture or Science Teachers, Farmers, Interested Individuals, Missionaries and Others who are interested in using as an outreach ministry.

LODGING

The meeting facility and host lodging is at Camp Living Water, 1510 West Deep Creek Road, Bryson City, NC. It adjoins the beautiful Great Smoky Mountains National Park. All rooms are $30/night single, $44/night double, including a big breakfast – payable upon arrival. Shared kitchen facilities are available at no extra charge. To reserve a room, call: 828-488-6012 or email: dclw@dnet.net. For more information, go to www.camplivingwater.com .

Producing Fuels from Agricultural Waste Course

Held when interest is sufficient – Bryson City, NC. Instruction will focus on the production of methane, biodiesel and ethanol from animal and plant waste, but other fuels will be covered. Profitable and practical uses of the by-products will also be included. Please contact us if you are interested in attending.

PRODUCING FUELS FROM AGRICULTURAL WASTES

Are you interested in economically converting agricultural wastes into valuable fuels and efficiently utilizing the by-products? If you do, plan to attend the Producing Fuels from Agricultural Wastes Course held at Camp Living Water, Bryson City, NC, September 27 – 30, 2005. Instruction will focus on the production of methane from animal and plant waste, but other fuels will be covered, such as ethanol and bio-diesel. Included will the construction of various types of digesters from locally available material and discarded products, day-to-day operation, utilizing the fuel for heating, running generators and other engines, the profitable use of the valuable by-products and alternative complimentary power production. This will prove to be a valuable and timely course for farmers, agriculture teachers, individuals interested in alternative energy and those who want to use as a “helps ministry” outreach. Come and enjoy the beauty of the Great Smoky Mountains and fellowship with others of like interest.

Sessions will be informal, allowing plenty of time for questions and discussions. The enthusiasm among course participants and instructors will be high. If you are already involved in the utilization of agricultural waste or alternative energy, bring a few photos on CD to share with the class. It will be a great time of fellowship & learning – an event that you will always remember!

LODGING

The meeting facility and host lodging is at Camp Living Water, 1510 West Deep Creek Road, Bryson City, NC. It adjoins the beautiful Great Smoky Mountains National Park. All rooms are $30/night single, $44/night double and and $18 for each person/night for 3 or more in a room, payable upon arrival. A hearty breakfast is included. Shared kitchen facilities are available. To reserve a room, indicate on the registration form. For more information, go to www.camplivingwater.com .

For those who want other lodging, Riverbend Lodging in Bryson City is a host facility. To make reservations, call them directly: 1-877-272-3125. Be sure to mention that you will be attending the course. For more information, go to: www.riverbendlodging.com . It is about four miles from Camp Living Water.

Sturgeon Culture Course

Many specialists agree that sturgeon culture will experience world wide growth during the years ahead. Instruction will focus on the reproduction, general production and management of the most desirable aquaculture species of sturgeon. Paddlefish production will also be covered. This four day course will be held when interest is sufficient.

Please contact us if you are interested in attending
